Our team of CAD technicians will reverse engineer the plans to check for inconsistencies in the design and ensure the project is constructible before the work has begun. Let us build your project model and add another level of QA/QC to your project.
The construction industry has used the traditional way of sharing information for a very long time, drafting the design intent on paper and sharing this information to the contractors. Over the past several decades the digital 3D delivery method has become more of the normal due to the technology we use now to build a project. The use of a 3D model is now required on most projects because the excavating equipment uses the models for grading and digging, the surveyors use the model for locating specific items on the project, and the model is used for quantity checks and balances, clash detection, and so much more.
Key Benefits of Integrating 3D Models with GPS Technology:
Most 3D models, currently, are used to create 2D paper plans, which are the contract document. However, these 3D design models are incomplete and not construction ready. Often these models have spikes in break lines, inaccurate triangle at interfaces and intersections, and most files from the designer are separated by civil, structural, architectural, and MEP. Merging all the design data into one large 3D model ensures that all aspects of a project are being checked together, because this is truly how a project is built. Also, building the 3D model ahead of time provides a new quality assurance to the project and client that in the past was never done. This is truly using reverse engineering to dissect each entity of the project before boots are on the ground.
3D Modeling for BIM:
Building Information Modeling is the holistic process of creating and managing information for a built asset. It’s much more than just creating 3D visualizations—it’s an intelligent, data-rich model that contains comprehensive information about every aspect of a building.
How GPS Cards Work:
GPS machine control consists of instruments that provide machine operators with data on equipment positioning, like bucket and blade positioning and desired grades, using devices including lasers, sonic equipment, total stations, and advanced 3D machine control technology.
service related FAQ’s
The industry will benefit by integrating real-time data and automation to improve precision, efficiency, and collaboration between machines and surveyors.
3D CAD files for machine control and surveyors can help manage change orders by providing accurate, updatable digital models that reflect design revisions, allowing teams to quickly compare planned versus actual work, quantify changes, and ensure alignment across all field and design operations.
Yes, using 3D CAD files with machine control and surveyors can help reduce energy consumption by optimizing designs, minimizing material waste, and improving precision during construction and equipment installation for more efficient operations.
3D CAD files provide precise, real-time guidance for machines and surveyors, improving accuracy, efficiency, and project coordination throughout the construction process.
Yes, 3D CAD files can help with predictive maintenance by providing accurate digital models that track changes over time, allowing surveyors and operators to detect shifts, wear, or structural issues early.
3D CAD files support TQM by providing precise digital models that improve accuracy, coordination, and verification for both machine control and surveying, ensuring consistent quality from design to execution.
Industry 4.0 is the integration of digital technologies like 3D CAD files with traditional tools such as tape measures, total stations, and multi-stations, combining precision and innovation to deliver smarter, more efficient results.
